PROJECT LOCATION:  HATAY/DÖRTYOL
CLIENT: KOÇOĞLU GROUP/COŞKUN ELECTRIC PRODUCTION
PURPOSE: ENERGY

PROJECT CHARACTERISTICS:
11.35 m High Concrete Gravity Weir Body
Uncontrolled Overflow Spillway with 160.76 m3/s Capacity
4400 m Long CTP Water Conveyance Line
166 m Gross Head
7.50 m3/s Project Discharge
9.835 MW Installed Capacity
2 Horizontal Axis Francis Turbines
35.672 GWh Annual Energy Production
In Operation Since 2013

SCOPE OF SERVICES: (2012-2013)
Planning and Feasibility Studies
Final Design Works
Preparation of Technical Specifications
Detail Design Works
Periodical Site Visits & Reporting During Construction
